Trung Tâm Báo Cháy Địa Chỉ 1-4 loop (JB-TB-TC5109)

Trung Tâm Báo Cháy Địa Chỉ 1-4 loop (JB-TB-TC5109)

Color menu display ▪ Intelligent bus control mode; max 255 addressable points per loop, max 4 loops, max 48 zones ▪ Loop card type design:1-4 loop card can be seledted ▪ Glass fuse per loop ▪ Black box function ▪ Independent controlling password for the specially needed gas recharging units ▪ Self-design loop protocol ▪ Wall-mounted structure, compact and exquisite ▪ Language: simplified Chinese and English ▪ Approvals：LPCB(EN54-2/4)CE
Lượt xem: 105
Giá: Liên hệ

Technical Specifications

Mains supply

AC230V (50HZ),Voltage range: +10%～-15%

Standby battery

12V/12AH sealed lead acid battery *2

LCD screen size

7-inch color LCD screen

Operating Environment

Temperature: -5°C～+50°C;Relative Humidity: ≤95%, non-condensing

Capacity

1020 addressable points

Communication Interface

RS232、RS485、CAN、USB

Dimension (L×W×H)

420mm×140mm×560mm

Output

Five output. Fault output. 24V power output. Loop output
