Designed to connect with active devices in field such as water flow switch,

pressure switch, position switch, signal valve and devices able to transmit

back switch signals

The built-in microprocessor processes messages intelligently

Plug-in structure

Non-polarized two-wire

Electronically addressed

Technical Specifications

Operating voltage:Loop: 24V (16V～28V)

Operating current:Standby current: ≤0.2mA;Alarm current: ≤0.8mA

Operating Environment:Temperature: -10°C～+55°C;Relative Humidity:

≤95%, non-condensing

Indicator: Red,Flashes when polling,Illuminates in action

Programming method: Electronically programming

Code range: One address is within 1～255

Material and color of enclosure: ABS; Porcelain white

Weight: About 110g (with base)

Mounting hole distance: 60mm

Dimension (L×W×H): 86mm×86mm×38mm (with base)
