Isolate the shorted circuit from the whole system to ensure normal

operation of other parts

After removing the shorted circuit fault, it can automatically bring the

Isolated part into the system

Optional 170 mA and 270 mA

Non-polarized two-wire

Technical Specifications

Operating current: Action current≤170 mA or 270 mA (B and ZX2 short circuit

here)

Load capacity:Loop 24V, 170mA;Loop 24V, 270mA (B and ZX2 short circuit

here)

Indicator: Yellow,Quiet in normal condition,Illuminates in action

Operating Environment:Temperature: -10°C～+50°C;Relative Humidity:

≤95%, non-condensing

Material and color of enclosure: ABS; Ivory white

Weight: About 110g (with base)

Mounting hole distance: 60mm

Dimension (L×W×H): 86mm×86mm×38mm (with base)
