Suitable for small houses or offices

9V alkaline battery and zinc-manganese dry battery

Power saving and reliable work

Low rate of false alarm, good anti-interference ability

Special chip and advanced optical maze to detect smoke

Self-test switch, test detector manually

Technical Specifications

Power supply: 6F22 DC9V battery

Operating current: ≤5uA

Alarm current: ≤7mA

Operating Environment:

 Temperature: -10°C～+50°C;

 Relative Humidity: ≤90%, non-condensing

Indicator: Red. Flashes about every 45s in normal condition

Alarm sound: ≥80dB @ 3m

Monitoring area: 60㎡～100㎡

Battery life: At least 1 year

Weight: 135g (with battery)

Mounting hole distance: 60mm

Dimension: Diameter 105mm, Height 54mm (with base)
