| PARAMETER |
SPECIFICATION |
| Size |
• 2.1" (5.3 cm) high; base determines diameter
• B501: 4.1” (10.4 cm) diameter |
| Shipping weight |
4.8 oz. (137 g) |
| Installation temperature |
• HM-FHSE-UL, HM-RHSE-UL: –4°F to 100°F
(–20°C to 38°C)
• HM-HTSE-UL: –4°F to 150°F (–20°C to 66°C) |
| Humidity range |
10% to 93% relative humidity (non-condensing) |
| Voltage range |
15 to 32 VDC peak |
| Standby current |
300 μA @ 24 VDC (one communication every five
seconds with LED blink enabled) |
| LED current |
6.5 mA @ 24 VDC |
| Fixed-temperature setpoint |
135°F (57°C) for the HM-FHSE-UL and HM-RHSE
UL; 190°F (88°C) for the HM-HTSE-UL |
| Rate-of-rise detection |
Responds to greater than 15°F (8.3°C) per minute |
