- TY7153 Đầu Phun Sprinkler K16.8 Tyco
- Mã sản phẩm: TY7153
- Giá: Liên hệ
- Lượt xem: 1066
Features:
- Full-scale fire testing has shown that the Ultra K17 can control fires with commodities up to Group A plastics, and eliminate the need for in-rack sprinklers
- Approved for storage heights of 25Ft. (7,6 m) and building heights to 30Ft. (9,1 m)
Hazard: Storage
Temperature: 155, 200
Thread: 3/4"
Approval: UL, C-UL, FM, NYC
Response: Standard Response
SIN Numbers: TY7153
Wrench: W8
Tech Data Sheet: View TFP330
Tech Data Translations[PDF]: SV
Revit Families:
Imperial: TY7153 [R3]
Metric: TY7153 [R3]- Chia sẻ:
