Dimensions

Depth     235.50 mm   |   9.27 in

Height    44.50 mm   |   1.75 in

Width    482.60 mm   |   19.00 in

Electrical Specifications

ANSI/TIA Category         3 | 6A | 6 | 6A | 8

Current Rating at Temperature      1.5 A @ 20 °C   |   1.5 A @ 68 °F

Dielectric Withstand Voltage, RMS, conductive surface         1,500 Vac @ 60 Hz

Dielectric Withstand Voltage, RMS, contact-to-contact         1,000 Vac @ 60 Hz

Insulation Resistance, minimum  500 MOhm

Environmental Specifications

Flammability Rating       UL 94 V-0

Operating Temperature         -10 °C to +60 °C (+14 °F to +140 °F)

Relative Humidity          Up to 95%, non-condensing

Storage Temperature     -40 °C to +70 °C (-40 °F to +158 °F)

General Specifications

Material Type         High-impact, flame retardant, thermoplastic   |   Powder-coated steel

Total Ports, quantity      24

Cable Type     Shielded & unShielded

Color      Black

Package Quantity  1

Rack Type       19 in

Rack Units      1.0

Standards

TIA/EIA 568-C.2

ISO/IEC 11801:2017
