Electrical Specifications

ANSI/TIA Category         6A

Transmission Standard          ANSI/TIA-568-C.2   |   ISO/IEC 11801 Class EA

Environmental Specifications

Flammability Rating       UL 94 V-0

General Specifications

Cable Type     shielded

Color      White

Mount Type  Keystone faceplates | blank patchpanel

Package Quantity  1

Packaging Type       Bag

Mechanical Specifications

Conductor Gauge, solid         26–22 AWG

Conductor Gauge, stranded           26–23 AWG

Conductor Type     Solid   |   Stranded

Contact Base Material  Beryllium copper

Contact Plating Material        Gold

Contact Plating Thickness      50II

Plug Insertion Life, minimum         1500 times

Termination Tool  Tool-less

Termination Type  IDC

Wiring    T568A   |   T568B

Temperature range  storing:    - 40° C to + 70° C

         during installation:    - 10° C to + 70° C

               in operation:    - 20° C to + 70° C

Standards

TIA/EIA 568-C Cat 6A

ISO/IEC 11801:2017 Class EA

UL Listed
